Basic Info.

Model NO.	UL-1061
Material Shape	Round Wire
Range of Application	Refractory
Certification	ISO9001, CE, RoHS, VDE
Brand	Bort
Warranty Time	at Least 10 Years for Proper Use
Appliance	Internal Wiring of Electronic&Electrical Equipment
Factory Management Standard	ISO9001:2008
Annual Capacity	300,000kms
Standard of Production	RoHS & Reach
Color Available	Any Colors
Delivery Time for Mass Production	15-30days
Delivery Time for Samples	3-5days
Weight	About 1kg/1000FT
Packaging	1000FT/Spool
Transport Package	Reel, Spool, Pallet
Trademark	BORT
Origin	China
HS Code	8544492900
Production Capacity	300000km/Year

Product Description

16-30AWG Environmental Electronic PVC Wire Conductor To Internal Wiring
Product Description:
★ Rated temperature: 80ºC
Rated voltage: 300V
★ Reference Standard: UL Subject 758, UL1581 & C22.2 NO.210.2
★ Tinned or bare, stranded or solid copper conductor,30-16 AWG
★ Colour-coded lead free SR-PVC insulation
★ Uniform insulation thickness to ensure easy stripping and cutting
★ Passes UL VW-1 & FT1 vertical flame test
★ Application: For internal wiring of electronic and electrical equipment,
protection is required where mechanical damage is possible

Conductor			Insulation		Maximum Resistance at 20ºCΩ/km
AWG	No./mm	Dia.mm	Nom. Thick.mm	Nom.Dia.mm	Maximum Resistance at 20ºCΩ/km
30	7/0.1	0.30	0.26	0.82	354
28	7/0.127	0.38	0.26	0.90	223
26	7/0.16	0.48	0.26	1.00	139
24	11/0.16	0.61	0.27	1.15	88.9
22	17/0.16	0.76	0.26	1.28	57.5
20	26/0.16	0.94	0.26	1.46	34.6
18	41/0.16	1.18	0.26	1.70	23.3
16	26/0.254	1.49	0.26	2.02	15.1

16-30AWG Environmental Electronic PVC Wire Conductor to Internal Wiring
